| Part Number |
CLS-1191-SM-520 |
CLS-1191-SM-820 |
| System |
Automatic high pressure steam sterilization |
| Operating temperature Sterilize |
105 to 135°C |
| Operating temperature Liquify |
60 to 110°C |
| Operating temperature Retain |
45 to 60°C |
| Operating temperature Preheat |
45 to 80°C |
| Operating temperature Dry |
135 to 150°C |
| Operating Ambient Temp. |
5 to 35°C |
| Maximum pressure capacity |
0.255MPa |
| Heating Sterilize Pipe |
1000W ×2 |
| Heating Drying Pipe |
110V/295W×2, 110V/455W×2 |
110V/275W ×2, 110V/625W ×2 |
| Temp. controller |
PlD controlled by microprocessor |
| Temp. setting / display |
Touch panel |
| Timer / Timer resolution |
Range: 0 or 1min to 99h59min / 1 min. |
| Safety Device |
Sterilize sensor error, sterilize SSR short circuit, dry sensor error, dry SSR short circuit, sterilize heater disconnection, dry heater disconnection, water level detection (liquid expansion method), independent chamber overheat protection, cover unlock error, chamber over pressure protection, under pressure protection, warning about setting error in cooling water container, memory error, pressure switch (0.25MPa), pressure safety valve (0.255MPa) |
| Internal dimensions |
⌀370 x D470 mm |
⌀370 x D750 mm |
| External dimensions WxDxH |
520 x 660 x 881 mm |
520 x 660 x 1161 mm |
| Internal capacity |
50L |
80L |
| Power source (50/60Hz) Voltage |
AC100-120V (no plug, round terminal) |
AC100-120V (no plug, round terminal) |
| Power source (50/60Hz) Sterilize current |
25-21A |
25-21A |
| Power source (50/60Hz) Dry current |
13.5A |
15.0A |
| Weight |
~113kg |
~137kg |
| Included accessories |
2 pcs. stainless steel mesh basket (⌀344 x D200 mm) |
2 pcs. stainless steel mesh basket (⌀344 x D300 mm) |
| |
Drain board x 1, drain bottle x 1, chemical indicator 1 set, filter x 1, droplet tray x 1 |
Drain board x 1, drain bottle x 1, chemical indicator 1 set, filter x 1, droplet tray x 1 |
