AREX 5 STIRRING HOT PLATE, ANALOG, 135MM CERALTOP PLATE, 115V, 60 HZ, VELP

Upgrade to digital with VTF for a precise thermoregulation. The AREX 5 is a robust and versatile hotplate stirrer suitable for applications ranging from basic to temperature-sensitive where precise sample thermoregulation is required. The AREX 5 can work stand-alone or be upgraded to digital by connecting the VTF digital temperature controller. The CerAlTopTM plate reaches a maximum temperature of 310°C; when connected with the VTF, the AREX 5 is able to thermoregulate the medium up to 300°C with an accuracy of ± 0.5 °C.

Easy-to-use and Safe. The AREX 5 hotplate stirrer ensures a high level of safety and protection for laboratory operators. Two illuminated indicators always inform the operator when the heating is on. Furthermore, the icon stays on when the temperature of the plate is above 50°C even if the instrument is switched off. The internal electronic parts are protected by the insulating disk, which, together with the robust die-cast aluminum housing, enables the AREX 5 to withstand even the most demanding laboratory environments and applications, such as when working with cold media (below 0°C). The 135 mm diameter top is protected from chemicals and scratches by the superior resistant CerAlTop™ ceramic coating. In addition, the AREX 5 hotplate stirrer is IP42 certified and it is backed up by a 3-year warranty.

 Powerful stirring performance for all lab applications. You can rely on the robust AREX 5 and its powerful brushless motor for everyday laboratory applications like sample and buffer solutions preparation, as it stirs volumes up to 20 liters (H2O). By turning the right knob of the AREX 5 it is possible to easily adjust the stirring speed from 100 up to 1500 rpm. The AREX 5 is equipped with VELP-engineered SpeedServo™ torque compensation technology that ensures constant speed even when the viscosity of the medium changes. Note: Hot plates have been designed and manufactured in compliance with the following standards CE, CSA, and UL.

  • Upgradable to digital with VTF ensuring temperature accuracy of ± 0.5°C.
  • Insulating disk to protect internal parts.
  • The 135 mm diameter top is protected from chemicals and scratches by the superior resistant CerAlTop™ ceramic coating.
  • Two illuminated indicators always inform the operator when heating is on and temperature above 50°C.
  • Stirs up to 20 l from 100 to 1500 rpm with SpeedServo™ counter reaction.
  • Brushless motor ensuring power and resistance over time.
Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1997-S-30
AREX 5 Stirring Hot Plate, Analog, 135mm CerAlTop Plate, 115V, 60 Hz, VELP
EACH
Call for
Availability
  ✱ Chemistry Equipment and Hardware Product line
Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1995-V-20Digital Thermoregulator ONLY, with Built In TimerEACH
15
CG-1995-V-22Vertical Support Rod OnlyEACH
453
  ✱ Chemistry Equipment and Hardware Product line
User InterfaceAnalog
Plate MaterialCerAlTop™ (ceramic coated aluminum alloy)
Stirring Volume20L
Speed ControlAnalog
Torque CompensationSpeedServo™
Heating ControlAnalog
Thermoregulation Accuracy± 0.5 °C (VTF)
Protection ClassIP 42
Weight3.7lb
Housing MaterialEpoxy painted aluminum structure
Plate Diameter135mm
Stirring Speed Range100 - 1500 rpm
MotorBrushless
Temperature RangeRoom temp - 310°C
External Temperature Sensor ConnectionVTF
Hot Plate Warning SystemIlluminated Icon (when the temperature is above 50°C)
Power Input630W
Dimensions (WxHxD)160 x 85 x 270mm (6.3 x 3.3 x 10.6in)
