CG-1968-W651

50L PROCESS REACTOR SYSTEM, SQUATTY, CYLINDRICAL, JACKETED, GLASS, 400MM FLANGE, BRUSHLESS DC ELECTRIC MOTOR

50L Squatty, Low Profile, glass reactor system with 400mm flange, on our innovative Kwik Mount support frame.

Complete 50L Squatty Reactor System Features:
• More Clearance: 50L Squatty Glass Reactor System with 400mm Flange Maximizes Clearance Under The Drain Valve
 Wider Access: 400mm ID Flange Provides Wider Access For Insertion or Probes, Baffles and Other Accessories without Interfering with Agitators
• Heavy Duty 2" Diameter Solid Stainless Steel Uprights and Heavy Duty PTFE Coated Aluminum Fittings Provide Maximum Strength and Chemical Durability
• Digital Temperature Monitor
• Heavy Duty Chemically Resistant Frame: Universal Motor Mount for Electric, Air, or XP Motors: Design Provides Greater Accessibility
• Electric Motor and Controller: Electric and XP Motor has Separate Controller with Digital Display. 1/4HP, 30-500RPM, 25 IN-LBS Chemstir Overhead Stirrer
• Reactor Jacket Graduation Scale on Both Sides
• Large Detachable Drain: 3" Beaded Pipe Zero Dead Space Detachable Drain Valve has Knob With Laser Etched Directional Arrows for Open and Close
• 7-Neck 400mm Inside Diameter Lid with Large 80mm Powder Addition Port
• Reactor Support Plate Holds Reactor Securely and Allows Easy Installation/Removal
• Pressure Relief Manifold System: Optional CG-1969-M High Flow Pressure Relief Manifold System with Insulated Hoses and Bulkhead Fittings
• Mobile: Large Swivel Casters with Locking Mechanisms

For Reactors Supplied with Mechanical Seal Stirrer Bearings: CLICK HERE

Email a Reactor Kit Specialist: [email protected]

Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-W651
50L Process Reactor System, Squatty, Cylindrical, Jacketed, Glass, 400mm Flange, Brushless DC Electric Motor
EACH
$38,583.95
Call for
Availability
  ✱ Manufactured Glassware Product Line
Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-T-50Large Zero Dead Space Drain Valve, 3" Beaded Pipe, Complete, Standard, 1-1/2" Beaded Pipe Side ArmEACH
$1,753.90
Call for
Availability
