CG-1968-W9100

100L PROCESS REACTOR SYSTEM, SQUATTY, CYLINDRICAL, JACKETED, GLASS, 400MM FLANGE, BRUSHLESS DC ELECTRIC MOTOR

100L Squatty, Low Profile, glass reactor system with 400mm flange. 100L glass reactor system on our innovative Kwik Mount support frame. Lexan safety shields surround the reactor with the front panel hinged for easy access.

Complete 100L Squatty Reactor System Features:
More Clearance: 100L Squatty Glass Reactor System with 400mm Flange Maximizes Clearance Under The Drain Valve
Wider Access: 400mm ID Flange Provides Wider Access For Insertion or Probes, Baffles and Other Accessories without Interfering with Agitators
• Heavy Duty 2" Diameter Solid Stainless Steel Uprights and Heavy Duty PTFE Coated Aluminum Fittings Provide Maximum Strength and Chemical Durability
• Digital Temperature Monitor
Heavy Duty Chemically Resistant Frame: Universal Motor Mount for Electric, Air, or XP Motors: Design Provides Greater Accessibility
Electric Motor and Controller: Electric and XP Motor has Separate Controller with Digital Display
• Reactor Jacket Graduation Scale on Both Sides
Large Detachable Drain: 3" Beaded Pipe Zero Dead Space Detachable Drain Valve has Knob With Laser Etched Directional Arrows for Open and Close
• 7-Neck 400mm Inside Diameter Lid with Large 80mm Powder Addition Port
• Reactor Support Plate Holds Reactor Securely and Allows Easy Installation/Removal
• Lexan Safety Shield On All Four Sides
Pressure Relief Manifold System: Supplied with CG-1969-M High Flow Pressure Relief Manifold System With Insulated Hoses and Bulkhead Fittings
• Mobile: Large Swivel Casters with Locking Mechanisms

Email a Reactor Kit Specialist: [email protected]

Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-W9100
100L Process Reactor System, Squatty, Cylindrical, Jacketed, Glass, 400mm Flange, Brushless DC Electric Motor
EACH
$46,713.65
Call for
Availability
  ✱ Not Subject to Discount
Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-T-55Large Zero Dead Space Drain Valve, 3" Beaded Pipe, Complete, Stabilizing Pin, 1-1/2" Beaded Pipe Side ArmEACH
$1,368.95
17
