20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR
20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR CG-2033-V UPGRADED MOTOR CONTROLLER 20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR OPTIONAL MANIFOLD SYSTEM 20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR

CG-1964 CG-1965 20L JACKETED

20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR

Pilot Plant Reactors 10L-100L

Complete glass reactor system on our NEW open air, auto-center stand. PLEASE NOTE: REACTOR STAND OVERALL HEIGHT WITH MOTOR AND CLEARANCE BELOW VALVE, ARE CALCULATED FOR ALL CHEMGLASS STIRRER BEARINGS, INCLUDING THE CG-2077-M MECHANICAL SEAL STIR BEARING.



• New & Improved Open Frame Design Provides Excellent Accessibility
• Support Frame with Oversized Rugged S.S. Uprights and Heavy Duty PTFE Coated Aluminum Fittings
• Improved Support Clamp Auto-Centers Reactor and Lid Allowing Quick Installation/Removal Of Reactor
• Perfluoro O-Rings On 60mm and 200mm Flanges
• S.S. Inlet/Outlet Adapters Available In M16 x 1 and M30 x 1.5 Allow Connection To Cooling/Heating Circulator
• Lower Support Plate, and PTFE Ring, Have a "V" Shaped Opening Allowing An Unobstructed View Of Bottom Valve
• Zero Dead Space Detachable Drain Valve Has Knob with Laser Etched Directional Arrows For Open and Close
• Electric or Air Motor. Optional XP Motor Available
• 5-Neck Lid with Large Powder Addition Funnel
• Digital Temperature Monitor
• Electric Motor Has Separate Digital Controller
• Reactor Jacket Graduated On Both Sides
• Removable S.S. Pipe Used To Support Side Shelf and Manifold System
• Support Bushings For Optional Safety Shield
• Heavy Duty Lockable Casters

For Reactors Supplied with Mechanical Seal Stirrer Bearings: CLICK HERE





Email a Reactor Kit Specialist: [email protected]

Item Number Item Description PQ PL Price Qty Avail Quantity
SKU: CG-1965-620
20L Process Reactor, Complete, Electric Motor, 70.1" OAH with Motor, 15.3" Clearance Below Valve
EACH
✱
$22,641.40
Call for Availability
Wishlist
SKU: CG-1964-620
20L Process Reactor, Complete, Air Motor, 67.0" OAH with Motor, 15.3" Clearance Below Valve
EACH
✱
$21,462.25
Call for Availability
Wishlist
SKU: CG-1965-620M
20L Process Reactor, Complete, Electric Motor, 70.1" OAH with Motor, 15.3" Clearance Below Valve, with CG-1969-M-04 Manifold System
EACH
✱
$25,642.25
Call for Availability
Wishlist
SKU: CG-1964-620M
20L Process Reactor, Complete, Air Motor, 67.0" OAH with Motor, 15.3" Clearance Below Valve, with CG-1969-M-04 Manifold System
EACH
✱
$24,306.80
Call for Availability
Wishlist
  • ✱ Manufactured Glassware Product Line
Item Number Item Description PQ PL Price Qty Avail Quantity
SKU: CG-1968-66
Coupling, 1" Beaded Pipe, "A" 1-7/8" X "B" 1-1/16", 35 in-lbs MAX Torque, 7/16" Hex Nut Size
EACH
✱
$136.80
Call for Availability
Wishlist
SKU: CG-1968-67
Coupling, 2" Beaded Pipe, "A" 3-1/8" X "B" 1-5/16", 60 in-lbs MAX Torque, 7/16" Hex Nut Size
EACH
✱
$177.75
Call for Availability
Wishlist
  • ✱ Chemistry Equipment and Hardware Product line
3L GAS SCRUBBERS, COMPLETE

CG-1830-10

3L GAS SCRUBBERS, COMPLETE

From $5,296.10
DISTILLATION KITS FOR 10L AND 20L PROCESS REACTOR SYSTEMS

CG-1965-D

DISTILLATION KITS FOR 10L AND 20L PROCESS REACTOR SYSTEMS

From $8,074.25
Pilot Plant Reactor Components and Accessories
MECHANICAL SEAL STIR BEARINGS, 2-3/8IN THREADED CONNECTION

CG-2077-M 2-3/8

MECHANICAL SEAL STIR BEARINGS, 2-3/8IN THREADED CONNECTION

From $2,482.40
Stirrer Bearings
FUNNELS, PROCESS REACTORS

CG-1767-R

POWDER FUNNELS, PROCESS REACTORS

From $370.95
Funnels
AIR OPERATED LOWER DRAIN VALVES FOR 10L THRU 50L REACTORS, AIR ACTUATED

CG-1968-V-01

AIR OPERATED LOWER DRAIN VALVES FOR 10L THRU 50L REACTORS, AIR ACTUATED

From $4,502.60
*In-Stock
Pilot Plant Reactor Components and Accessories
PT100 TEMPERATURE SENSORS, SHIELDED CABLE, PFA COATED

CG-1978-P9

PT100 RTD TEMPERATURE SENSORS, SHIELDED CABLE, PFA COATED, PT-100

From $418.25
Thermocouples & PT100 Sensors
HOSES, INSULATED, HUBER

CG-1978-H M16

HOSES, INSULATED, HUBER, M16

From $0.00
Hoses, Fittings & Accessories
HUBER COOLING/HEATING UNISTAT CIRCULATORS, -85 TO 250°C

Unistat -85 to 250°C

HUBER COOLING/HEATING UNISTAT CIRCULATORS, -85 TO 250°C

From $0.00
Circulators & Accessories
HUBER COOLING/HEATING UNISTAT CIRCULATORS, -45 TO 250°C

Unistat -45 to 250°C

HUBER COOLING/HEATING UNISTAT CIRCULATORS, -45 TO 250°C

From $0.00
Circulators & Accessories
HUBER COOLING/HEATING UNISTAT CIRCULATORS, -55 TO 250°C

Unistat -55 to 250°C

HUBER COOLING/HEATING UNISTAT CIRCULATORS, -55 TO 250°C

From $0.00
Circulators & Accessories
UNISTAT BATH FLUID, DW-THERM HT, +20 TO +340°C, HUBER®

CG-1978-F DW

BATH FLUID, UNISTAT, HUBER®, DW-THERM, -90 TO +200°C

From $0.00
UNISTAT BATH FLUID, DW-THERM HT, +20 TO +340°C, HUBER®

CG-1978-F DW HT

UNISTAT BATH FLUID, DW-THERM HT, +20 TO +340°C, HUBER®

From $0.00
*In-Stock
Circulator Heat Transfer Fluids
HUBER COOLING/HEATING UNISTAT CIRCULATORS, -45 TO 250°C, WATER COOLED

CG-1978-U548

HUBER COOLING/HEATING UNISTAT CIRCULATORS, -45 TO 250°C, WATER COOLED

From $0.00
20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC MOTOR, MECHANICAL BEARING

CG-1965-MB 20L JACKETED

20L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC MOTOR, MECHANICAL BEARING

From $24,408.05
*In-Stock
GLASS BAFFLES, PROCESS REACTORS, 2L THRU 50L, KORZUN†

CG-1971

GLASS BAFFLES, PROCESS REACTORS, 10L THRU 50L, KORZUN†

From $622.15
Glass
