CG-1968 CG-1970 30L JACKETED

30L PROCESS REACTORS, CYLINDRICAL, JACKETED, ELECTRIC OR AIR MOTOR

Pilot Plant Reactors 10L-150L

Complete reactor system on our NEW open air stand. PLEASE NOTE: REACTOR STAND OVERALL HEIGHT WITH MOTOR AND CLEARANCE BELOW VALVE, ARE CALCULATED FOR ALL CHEMGLASS STIRRER BEARINGS, INCLUDING THE CG-2077-M MECHANICAL SEAL STIR BEARING.

Features:

• Motor Mount Arm Can Unlock And Swing Out Giving Greater Access To Reactor
• Digital Temperature Monitor
• Electric And XP Motor Has Separate Controller With Digital Display
• Smaller Footprint Support Frame With Oversized Rugged S.S. Uprights And Heavy Duty PTFE Coated Aluminum Fittings
• Reactor Jacket Graduation Scale On Both Sides
• Lower Safety Ring
• Zero Dead Space Detachable Drain Valve Has Knob With Laser Etched Directional Arrows For Open And Close
• Electric Or Air Motor Optional XP Motor Available
• Open Frame Design Provides Excellent Accessibility
• 7-Neck Lid With Large Powder Addition Port
• Reactor Support Plate Holds Reactor Securely And Allows Easy Installation/Removal Of Reactor By One Person
• Ridge Clamp Accepts 1/2” Rod And Adds Additional Support For Large Glassware
• S.S. Inlet/Outlet Adapters Available In M16 X 1 And M30 X 1.5 Allow Connection To Cooling/Heating Circulator
• Heavy Duty Lockable Casters

For Reactors Supplied with Mechanical Seal Stirrer Bearings: CLICK HERE

Email a Reactor Kit Specialist: [email protected]

Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-630
30L Process Reactor, Complete, Electric Motor, 82.6" OAH with Motor, 18.6" Clearance Below Valve
EACH
Call for
Availability
CG-1970-630
30L Process Reactor, Complete, Air Motor, 79.0" OAH with Motor, 18.6" Clearance Below Valve
EACH
Call for
Availability
CG-1968-630M
30L Process Reactor, Complete, Electric Motor, 82.6" OAH with Motor, 18.6" Clearance Below Valve, with CG-1969-M-06 Manifold System
EACH
Call for
Availability
CG-1970-630M
30L Process Reactor, Complete, Air Motor, 79.0" OAH with Motor, 18.6" Clearance Below Valve, with CG-1969-M-06 Manifold System
EACH
Call for
Availability
  ✱ Manufactured Glassware Product Line
Item NumberItem DescriptionPQPriceQty AvailQuantity
CG-1968-66Coupling, 1" Beaded Pipe, "A" 1-7/8" X "B" 1-1/16", 35 in-lbs MAX Torque, 7/16" Hex Nut SizeEACH
Call for
Availability
CG-1968-67Coupling, 2" Beaded Pipe, "A" 3-1/8" X "B" 1-5/16", 60 in-lbs MAX Torque, 7/16" Hex Nut SizeEACH
Call for
Availability
  ✱ Chemistry Equipment and Hardware Product line
