CLS-3599-C

MISTRAL SAMPLE CONCENTRATOR, ULTRAVAP, PORVAIR

  • Fully liquid handling robot-compatible dry down station
  • Plate shuttle sends/retrieves plates from robot deck
  • Adjustable shuttle position and height
  • Intuitive graphical color touch screen display
  • Up to 15 stored evaporation programs
  • Up to 5 programmable steps per method
  • On board gas management
  • Master & multiple slave configuration supported
  • Remote control from PC option
  • Reversible screen for integration at side of robot
  • Built-in fume management and duct connector
  • Faster evaporation times
  • Choice of 24-, 48-, 96- and 384-well heads
  • Small footprint to fit in your hood
  • Energy-saving Eco mode extends heater and fan life

The Ultravap® Mistral from Porvair Sciences is designed to remove the traditional laboratory ‘bottleneck’ of solvent evaporation from microplates. Fully automating the dry-down step has always been impossible because it is difficult to interface liquid handling robots with traditional centrifugal-type evaporators. The Ultravap Mistral design, by dispensing with the rotating arm of the centrifuge, overcomes this problem and is much better positioned to link with your robot. With more than 20 years’ experience in producing deep well microplates, Porvair Sciences has thoroughly researched the problems of drying down organic solvents in plates. This has led to the ultimate microplate blow down evaporator – the Ultravap Mistral.

The Ultravap Mistral is the most sophisticated automation-friendly model yet, giving significant throughput advantages to laboratories looking to optimize microplate sample preparation. The new Ultravap Mistral has been designed in close co-operation with the leading suppliers of laboratory liquid handling robots. The result is a fully robot compatible evaporator, suitable for integration directly with the following leading laboratory liquid handling robots:

Hamilton Robotics l Tecan l Perkin Elmer l Beckman Coulter l Agilent

Designed with the demands of linear robots very much in mind, the Ultravap Mistral offers a plate shuttle which can serve and retrieve plates from the deck of most liquid handlers. The color touch-screen controlled dry down station accepts interchangeable 24-, 48-, 96- or 384-needle heads and comes complete with clear safety screens and integral fume management leading to a 4-inch duct adaptor that incorporates a fan for high speed fume removal.

PLEASE CONTACT TECH SERVICES TO RECEIVE A QUOTATION ON THESE SYSTEMS: [email protected]

Item NumberItem DescriptionPQPriceQty AvailQuantity
CLS-3599-C-100
Mistral Sample Concentrator, Without Needle Head, Porvair, 110V
EACH
$22,093.60
Call for
Availability
CLS-3599-C-100E
Mistral Sample Concentrator, Without Needle Head, Porvair, 220V
EACH
$22,093.60
Call for
Availability
Item NumberItem DescriptionPQPriceQty AvailQuantity
CLS-3599-C-10296 Needle Head with Spiral Needles, for all Porvair EvaporatorsEACH
$3,058.95
Call for
Availability
Add to Favorites
CLS-3599-C-10496 Needle Head with Straight Needles, for all Porvair EvaporatorsEACH
$2,446.95
Call for
Availability
Add to Favorites
CLS-3599-C-106384 Needle Head with Straight Needles, for Ultravap RC Mistral & Levante OnlyEACH
$3,722.00
Call for
Availability
Add to Favorites
CLS-3599-C-10812 Needle Head Straight, for all Porvair Evaporators, 48mm Needles, with GasketEACH
$2,446.95
Call for
Availability
Add to Favorites
CLS-3599-C-11012 Needle Head Straight, for all Porvair Evaporators, 38mm Needles, with GasketEACH
$2,399.00
Call for
Availability
Add to Favorites
CLS-3599-C-11224 Needle Head Straight, for all Porvair EvaporatorsEACH
$2,446.95
Call for
Availability
Add to Favorites
CLS-3599-C-114Dedicated 48 Needle Head Straight, for use with HPLC Vial Adapter, for all Porvair EvaporatorsEACH
$2,446.95
Call for
Availability
Add to Favorites
CLS-3599-C-116Vial Adapter for HPLC Vials, 48 x 1.5mL (Finneran), Black PolypropyleneEACH
$296.00
Call for
Availability
Add to Favorites
CLS-3599-C-118Gasket, Needle Head Manifold, for all Porvair EvaporatorsEACH
$197.70
Call for
Availability
Add to Favorites
CLS-3599-C-12024-Well 12mm I.D. Vial Holder, Solid Aluminium, for all Porvair EvaporatorsEACH
$1,246.60
Call for
Availability
Add to Favorites
CLS-3599-C-122Disposable Vial Rack, Plastic, with Clear Bottom, for (24) 13.75mm O.D. Glass VialsPK5
$84.50
Call for
Availability
Add to Favorites
CLS-3599-C-124Replacement LCD Screen for Ultravap RCEACH
$1,098.00
Call for
Availability
Add to Favorites
CLS-3599-C-128Mistral CAN bus interface cable with RS232 initiator and CAN terminator plugsEACH
$478.30
Call for
Availability
Add to Favorites
  ✱
