CG-360

INTERNAL THREADS, GLASS PORTION ONLY

Hose Connections and Accessories

Internal glass thread for use with CG-362, CG-363, CG-364, and CG-366 PTFE bushings. Tubing OD listed is the shank OD of the thread.

Internal Thread Specifications:
#7 Internal Thread: 12.7mm Tube OD, Accepts 6-7mm OD Tubing
#11 Internal Thread: 16mm Tube OD, Accepts 9-10.5mm OD Tubing
#15 Internal Thread: 22mm Tube OD, Accepts 12.5-14mm OD Tubing
#25 Internal Thread: 32mm Tube OD, Accepts 24-25mm OD Tubing
#50 Internal Thread: 57mm Tube OD, Accepts 47-48mm OD Tubing

Item NumberMPNItem DescriptionPQPriceQty AvailQuantity
CG-360-01
#7 Internal Thread, Glass Only
EACH
288
CG-360-02
#11 Internal Thread, Glass Only
EACH
258
CG-360-03
#15 Internal Thread, Glass Only
EACH
324
CG-360-05
#25 Internal Thread, Glass Only
EACH
84
CG-360-06
7644-25
#50 Internal Thread, Glass Only
EACH
122
