CLS-1174-P

BOTTLES, CLEAR, PRESSURE RESISTANT, MEDIA STORAGE, DURAN

With easy-to-read scale and large labelling field for easy marking, in fired-on, highly durable white ceramic. Pressure resistance conforms to DIN ISO 1595, confirmed by GS marking (TÜV ID: 0000020716). Vacuum and/or pressure resistant from –1 to 1.5 bar due to modified geometry (based on ISO 4796-1). When pressure loaded the following apply: thermal shock resistance 30 K and maximum usage temperature +140 °C. Blue scale for visual differentiation from the standard laboratory bottle.

  • Sizes 100 to 1000mL
  • Blue Printing to visually distinguish from standard media bottles
  • Vacuum or pressure resistance from -1 bar to +1.5 bar
  • Typical Applications Include: Safe for working under pressure or vacuum, sampling under pressure, storage of gas generating media, storage of volatile solvents, vacuum filtration.



Please Note: Bottles are also available in Amber or with Protect safety coating. Contact [email protected] for a quotation.

Item NumberItem DescriptionPQPriceQty AvailQuantity
CLS-1174-P-100
Bottle, 100mL, Pressure Resistant, Media Storage, Clear, GL-45, Duran
C10
Call for
Availability
CLS-1174-P-250
Bottle, 250mL, Pressure Resistant, Media Storage, Clear, GL-45, Duran
C10
5
CLS-1174-P-500
Bottle, 500mL, Pressure Resistant, Media Storage, Clear, GL-45, Duran
C10
1
CLS-1174-P-1L
Bottle, 1L, Pressure Resistant, Media Storage, Clear, GL-45, Duran
C10
1
  † Reusable Glass/Plastics
Part NumberCapacity (mL)DIN Thread (GL)Dia (mm)Height (mm)
CLS-1174-P-1001004556100
CLS-1174-P-2502504570138
CLS-1174-P-5005004586176
CLS-1174-P-1L100045101225



Pressure/Vacuum Chart:

BOTTLES, CLEAR, PRESSURE RESISTANT, MEDIA STORAGE, DURAN
