CLS-3450

OVENS, VACUUM

The Vacuum ovens are durably constructed with seamless welds and strong bracing. All of the vacuum ovens are built with a stainless steel chamber for exceptional durability. Ovens incorporate solid brass vacuum valves with PTFE seats to prevent leaks. The double plenum design exceeds CE safety requirements resulting in a cool outer surface.
The doors on these units have positive latch handles with spring-loaded glass to facilitate a good vacuum seal without hinge binds that shorten the gasket life. A selection of gaskets (for specific applications) and a small footprint increase the versatility of these ovens.
The unique cross-flow ventilation forces inert gas to fill the entire chamber. Users can choose from 3/8 inch orifices or a KF25 fitting to withstand heavy use, minimize draw-down time and achieve low vacuum levels. We offer a full line of gaskets to suit applications involving high temperatures, acids, or solvents. Ovens have a 24 month limited warranty.

Item NumberItem DescriptionPQPriceQty AvailQuantity
CLS-3450-006
0.6 Cu. Ft. Oven, Vacuum, 120V
EACH
$5,327.00
Call for
Availability
CLS-3450-206
0.6 Cu. Ft. Oven, Vacuum, 230V
EACH
$5,859.00
Call for
Availability
CLS-3450-017
1.7 Cu. Ft. Oven, Vacuum, 120V
EACH
$6,833.00
Call for
Availability
CLS-3450-217
1.7 Cu. Ft. Oven, Vacuum, 230V
EACH
$7,516.00
Call for
Availability
CLS-3450-045
4.5 Cu. Ft. Oven, Vacuum, 120V
EACH
$13,218.00
Call for
Availability
CLS-3450-245
4.5 Cu. Ft. Oven, Vacuum, 230V
EACH
$14,539.00
Call for
Availability
  ✱ Life Science Equipment Product Line
ModelCLS-3450-006CLS-3450-017CLS-3450-045
NumbersCLS-3450-206CLS-3450-217CLS-3450-245
System TypeVacuum OvenVacuum OvenVacuum Oven
Capacity16L / 0.6 cu ft47L / 1.7 cu ft127.5L / 4.5 cu ft
Dimensions (w x d x h)
Exterior:17.5 x 22.8 x 23.5 in.20.5 x 29.5 x 26.3 in.26.5 x 34.5 x 32.3 in.
Interior:9 x 12 x 9 in.12 x 20 x 12 in.18 x 24 x18 in.
Temperature RangeAmbient +10 to 220°CAmbient +10 to 220°CAmbient +10 to 220°C
Temperature Uniformity±6% of Set-Point±6% of Set-Point±6% of Set-Point
High Limit ControlYesYesYes
Shelving3 Supplied / 3 Max3 Supplied / 3 Max3 Supplied / 3 Max
